Gemini 3200 Catamarans For Sale

sales on record

years built

1990–1993

length range

32–32 ft

for sale now

The 3200 is an evolution of 3000 design and has all the popular features as the original with the added interior space. Has kick-up centerboards and transom-hung, lifting rudders. Draft is only 1’ 6” when centerboards and rudders up – great for cruising shallow creeks, rivers and bays, and 4’ 6” when down –for reduced leeway when sailing upwind. Followed by 3400 version in 1993 that added molded transom steps.

Specifications

Type	Multihull
Years Built	1990 – 1993
Builder	Performance Cruising Inc. (Mayo, MD, USA)
Designer	Tony Smith
Construction	Molded hull and deck with large single interior mold over the bridgedeck coming back from the forward bulkhead to the aft lockers. Glassed into the bridgedeck prior to lifting. Hull and deck are mechanically and chemically bonded with a polyester putty and bolts and backing nuts every four inches with a double gunwhale guard over the bond. Hull is laminate of woven roving and matt with polyester resin over an initial layer of gel coat with vinylester resin and a veil of fiberglass fabric for blister protection. Deck has half inch end grain balsa sandwich on the foredeck, around cockpit and across the cabin top. Deck fitting are drilled through solid glass.

Dimensions

LOA	32' 0" ( 9.75 m)
LWL	27' 6" (8.4 m)
Beam	14' 0" ( 4.27 m)
Headroom	6 ft 3 in
Draft	Max Draft: 4' 6" ( 1.37 m) / Min Draft: 1' 6" ( .46 m); centerboards are mahogany plywood 2 inch thick, simple rope and rum lift.
Mast Height	42' 0" ( 12.8 m)

Performance

Displacement	7000 lbs
Speed	Cruising Speed: 6.5 Knts Max Speed: 7.5 Knts
Engines	40hp outboard

Educational Articles

Dec 12, 2020

Gemini 3200 Owner Review and Interview S/V Epiphany Hull # 316

Today we have Joseph of S/V Epiphany – a Gemini 3200. He refitted his 3200 from the ground up. He did a massive amount of work to spend a lot of money, and he is a great guy to tell us all about the model. He goes through all the issues he has had and gives invaluable advice to people considering buying a classic Gemini. Sailing performance, common issues, and maneuverability are all covered. Please see below for the video of our interview, refit photos, and a transcript of the Q&A.…

Read Article
